MaterialX.Net

A single-package .NET binding for MaterialX - the open standard for representing rich material and look-development content in computer graphics. Targets .NET 10 and uses LibraryImport source-generated P/Invoke.

The NuGet ships:

• MaterialX.Net.dll - managed wrapper API (MaterialX.Document, Node, NodeGraph, Input, value types, ...).
• runtimes/<rid>/native/MaterialXC.{dll,so,dylib} - a tiny extern "C" shared library that statically links the upstream MaterialX archives. This is the only native artifact you need to ship; MaterialX itself is C++ and cannot be P/Invoked directly.
• runtimes/any/native/libraries/ - the MaterialX standard data libraries (stdlib, pbrlib, bxdf, lights, cmlib, nprlib, mdl, targets). The bundled MSBuild targets stage them next to your assembly as libraries/ at build/publish time, where Document.LoadStandardLibraries() picks them up automatically.

Quick start

Build a material and write it to disk:

using MaterialX;

using var doc = Document.Create();
doc.LoadStandardLibraries(); // resolves the bundled libraries/ folder

using var surface = doc.AddNode("standard_surface", "shader1", "surfaceshader");
using var baseColor = surface.GetOrAddInput("base_color", "color3");
baseColor.SetValue(new Color3(0.8f, 0.2f, 0.1f));

doc.WriteToXmlFile("out.mtlx");

Generating Vulkan GLSL (or desktop GLSL / ESSL / WGSL)

Once a document has at least one renderable element (a surfacematerial, standard_surface, etc.), you can generate real shader source straight from the managed API:

using MaterialX;
using System.Linq;

const string Mtlx = """
<?xml version="1.0"?>
<materialx version="1.39">
  <standard_surface name="SR1" type="surfaceshader">
    <input name="base_color" type="color3" value="0.8, 0.2, 0.2" />
  </standard_surface>
  <surfacematerial name="M1" type="material">
    <input name="surfaceshader" type="surfaceshader" nodename="SR1" />
  </surfacematerial>
</materialx>
""";

using var doc = Document.ReadFromXmlString(Mtlx);
doc.LoadStandardLibraries();

// Pick a backend: Vulkan | Glsl400 | Essl300 | Wgsl
using var gen = ShaderGenerator.Create(ShaderTarget.Vulkan);
using var ctx = GenContext.Create(gen);
ctx.AddStandardLibrarySearchPath(); // resolves "libraries/..." includes

var renderable = doc.Renderables.First();
using var shader = gen.Generate(renderable, ctx, "MyShader");

string vertexSrc = shader.GetSourceCode(ShaderStage.Vertex);
string pixelSrc  = shader.GetSourceCode(ShaderStage.Pixel);

Console.WriteLine($"target={gen.Target} vertex={vertexSrc.Length} pixel={pixelSrc.Length}");

The pixel stage is the full MaterialX standard_surface implementation as Vulkan-flavored GLSL (#version 450 + layout(set=, binding=) decorations on every UBO and sampler) - i.e. source you can feed straight into glslangValidator -V / shaderc to produce SPIR-V for vkCreateShaderModule. Switching ShaderTarget swaps backends with no other changes required: Glsl400 for desktop OpenGL, Essl300 for GLES 3 / WebGL 2, Wgsl for WebGPU.

Building the native shim

The package ships pre-built shims for win-x64, linux-x64, osx-arm64 (Apple Silicon), and osx-x64 (Intel Macs). Because the upstream MaterialX_MacOS_Xcode_16_Python313 release ships arm64-only static archives, the osx-x64 shim is built against a from-source MaterialX build performed on an Intel macOS runner; the other RIDs link against the prebuilt SDK zips. To rebuild them from source, see native/MaterialXC/README.md.

Why a C-shim?

MaterialX is a C++ API (templates, std::shared_ptr, namespaces). The upstream distribution ships only static archives (.a / .lib) plus pybind11 Python modules - nothing that can be LibraryImport'd directly from .NET. The MaterialXC shim under native/MaterialXC/ exposes the subset of MaterialX needed by the managed API as a flat extern "C" surface using opaque handles (mx_document_t, mx_node_t, ...). Extending the binding = adding a function to MaterialXC.h/.cpp and mirroring it in src/Native/MaterialXNative.cs.

License

MaterialX.Net is licensed under Apache-2.0, matching upstream MaterialX. The bundled native binaries and data libraries are © Academy Software Foundation / contributors and redistributed under the same license.
