Prosa: Formally Proven Schedulability Analysis

This repository contains the main specification & proof development of the Prosa open-source project. Technically, Prosa is a library for the Rocq Prover (previously known as the Coq Proof Assistant).

The Prosa project was launched in 2016. From 2018–2021, Prosa was refactored and enhanced in the context of the RT-Proofs research project (funded jointly by ANR and DFG, projects ANR-17-CE25-0016 and DFG-391919384, respectively).

Prosa was developed further in the context of the TOROS ERC project (2019–2023, grant agreement No 803111).

Prosa continues to be maintained and developed by the MPI-SWS Real-Time Systems group and contributors. Patches and merge requests are very welcome!

Documentation

Up-to-date documentation for all branches of the main Prosa repository is available on the Prosa homepage:

• https://prosa.mpi-sws.org/branches

Publications

Please see the list of publications on the Prosa project's homepage.

Classic Prosa

All results published prior to 2020 used the "classic" version of Prosa as first presented at ECRTS'16. Classic Prosa has been superseded by this development and is no longer being maintained. Refer to the classic-prosa branch to find this original version of Prosa.

Directory and Module Structure

The directory and module structure is organized as follows. First, the main parts, of which there are currently six.

• behavior: The behavior namespace collects basic definitions and properties of system behavior (i.e., it defines Prosa's trace-based semantics). There are no proofs here. This module is mandatory: all results in Prosa rely on the basic trace-based semantics defined in this module.
• model: The model namespace collects all definitions and basic properties of various system models (e.g., sporadic tasks, arrival curves, various scheduling policies, etc.). There are only a few proofs here. This module contains multiple, mutually exclusive alternatives (e.g., periodic vs. sporadic tasks, uni- vs. multiprocessor models, constrained vs. arbitrary deadlines, etc.), and higher-level results are expected to "pick and choose" whatever definitions and assumptions are appropriate. These models are axiomatic in the sense that they are collections of hypotheses and not necessarily backed by concrete implementations (but see below).
• analysis: The analysis namespace collects all definitions and proof libraries needed to establish system properties (e.g., schedulability, response time, etc.). This includes a substantial library of basic facts that follow directly from the trace-based semantics or specific modelling assumptions. Virtually all intermediate steps and low-level proofs will be found here.
• results: The results namespace contains all high-level analysis results.
• implementation: This module collects concrete implementations of some of the axiomatic models and scheduling policies to which the results apply. These are used to instantiate (i.e., apply) high-level results in an assumption-free environment for concrete job and task types, which establishes the absence of contradictions in the axiomatic models refined by the implementations.
• implementation.refinements: The refinements needed by POET to compute with large numbers, based on CoqEAL.

Furthermore, there are a couple of additional folders and modules.

• util: A collection of miscellaneous "helper" lemmas and tactics. Used throughout the rest of Prosa.
• scripts/: Scripts and supporting resources required for continuous integration and documentation generation.

Side-effects

Importing Prosa changes the behavior of ssreflect's done tactic by adding basic lemmas about real-time systems.

Ltac done := solve [ ssreflect.done | eauto 4 with basic_rt_facts ].

Prosa overwrites the default obligation tactic of Rocq's standard library with idtac. Refer to util.tactics for details.

Installation

The following methods are appropriate if you want to simply use some theorems from a stable, released version of Prosa, but don't plan on modifying Prosa itself. To work on Prosa, please instead follow the instructions for manually compiling from sources given further below.

Preferred Method: With opam (the OCaml Package Manager)

Prosa can be installed using opam (>= 2.0).

opam repo add rocq-released https://rocq-prover.org/opam/released
opam update
opam install coq-prosa

From Sources with opam

OPAM can also be used to install a local checkout. For example, this is done in the CI setup (see .gitlab-ci.yaml).

opam repo add rocq-released https://rocq-prover.org/opam/released
opam update
opam pin add -n -y -k path coq-prosa .
opam install coq-prosa

From Sources With esy

Prosa can be installed using the esy package manager.

Installing esy

esy itself can typically be installed through npm. It should look something like this on most apt-based systems:

sudo apt install npm
sudo npm install --global esy@latest

Installing Prosa

With esy in place, it is easy to compile Prosa in one go. To download and compile all of Prosa's dependencies (including the Rocq Prover), and then to compile Prosa itself, simply issue the command:

esy

Note that esy uses an internal compilation environment, which is not exported to the current shell. To work within this environment, prefix any command with esy: for instance esy coqide to run your system’s CoqIDE within the right environment. Alternatively, esy shell opens a shell within its environment.

Manual Compilation From Sources

To compile Prosa from sources, in particular if you plan to modify it, we strongly suggest to set up an opam switch with all required dependencies installed.

Quick Setup

For convenience, the creation of a suitable opam switch is automated by the script mk-opam-switch.sh (which can be found in the scripts/ folder of the Prosa repository). Assuming you have opam already configured (run opam init if not), simply run this script to create a new "switch" with all required dependencies already in place.

Dependencies

Besides Rocq itself, Prosa depends on

1. the ssreflect library of the Mathematical Components project,
2. the Micromega support for the Mathematical Components library provided by mczify, and
3. the Coq Effective Algebra Library (optional, needed only for POET-related refinements).

These dependencies can be easily installed with OPAM.

opam install -y rocq-prover rocq-mathcomp-ssreflect coq-mathcomp-zify coq-coqeal

The Prosa team seeks to always track the latest stable versions of rocq-prover and mathcomp. Sometimes older versions may still work, but we do not explicitly maintain compatibility with older versions of any dependency due to limited engineering time.

Compiling Prosa

Assuming all dependencies are available (either via OPAM or compiled from source, see the Prosa setup instructions), compiling Prosa can be done by just typing:

make -j

Depending on how powerful your machine is, this will take a few minutes.

The library can then be installed with:

make install

To compile the POET-related refinements (which require CoqEAL to be installed and inject a dependency on the proof irrelevance axiom), first install the main Prosa library with the two commands above, then type:

make refinements

The newly compiled files can then be installed with:

make install

Generating HTML Documentation

Once the library has been compiled, the coqdoc documentation (as shown on the web page) can be easily generated with:

• make htmlpretty -j --- pretty documentation based on CoqdocJS (can hide/show proofs),
• make gallinahtml -j --- just the specification, without proofs,
• make html -j --- full specification with all proofs.

Since coqdoc requires object files (*.vo) as input, please make sure that the code compiles.

Commit and Development Rules

We very much welcome external contributions. Please don't hesitate to get in touch!

To make things as smooth as possible, here are a couple of rules and guidelines that we seek to abide by.

1. Always follow the project coding and writing guidelines.

2. Make sure the master branch "compiles" at each commit. This is not true for the early history of the repository, and during certain stretches of heavy refactoring, but going forward we strive to keep it working at all times.

3. It's okay (and even recommended) to develop in a (private) dirty branch, but please clean up and rebase your branch (i.e., git rebase -i) on top of the current master branch before opening a merge request.

4. Create merge requests liberally. No improvement is too small or too insignificant for a merge request. This applies to documentation fixes (e.g., typo fixes, grammar fixes, clarifications, etc.) as well.

5. If you are unsure whether a proposed change is even acceptable or the right way to go about things, create a work-in-progress (WIP) merge request as a basis for discussion. A WIP merge request is prefixed by "WIP:" or "Draft:".

6. We strive to have only "fast-forward merges" without merge commits, so always re-base your branch to linearize the history before merging. (WIP branches do not need to be linear.)

7. Recommendation: Document the tactics that you use in the list of tactics, especially when introducing/using non-standard tactics.

8. If something seems confusing, please help with improving the documentation. :-)

9. If you don't know how to fix or improve something, or if you have an open-ended suggestion in need of discussion, please file a ticket.
