SVG LLM Generator for Inkscape

Generate SVG graphics using AI directly within Inkscape

A powerful Inkscape extension that leverages multiple AI providers (OpenAI, Anthropic Claude, Google Gemini, and local Ollama) to generate scalable vector graphics from text descriptions.

📺 Demo

Click to watch the full tutorial on YouTube

📋 Table of Contents

Features
Requirements
Installation
Quick Start
Usage Guide
Configuration
Provider Setup
Customization
Troubleshooting
Contributing
License

✨ Features

🤖 Multiple AI Providers
- OpenAI: GPT-4, GPT-4 Turbo, GPT-3.5
- Anthropic: Claude 3.5 Sonnet, Claude 3 Opus
- Google: Gemini 1.5 Flash, Gemini 1.5 Pro
- Ollama: Local models (Llama, Mistral, etc.)
🎨 Rich Style Options
- Style presets (minimal, detailed, flat, outline, geometric, etc.)
- Color schemes (monochrome, warm, cool, pastel, vibrant, etc.)
- Complexity levels (simple, medium, complex)
- Stroke style control
📐 Flexible Sizing
- Preset sizes (small, medium, large, xlarge)
- Custom dimensions
- Aspect ratios (square, landscape, portrait, widescreen, banner)
🎯 Smart Positioning
- Center, origin, or next to selection
- Multiple variations side-by-side
- Automatic grouping with custom names
⚙️ Advanced Features
- Selection context awareness
- Prompt presets (icon, logo, diagram, pattern, etc.)
- Gradient and animation support
- Accessibility options (title/desc)
- Prompt history tracking
- Retry logic for reliability

📦 Requirements

Component	Version	Purpose
Inkscape	1.0+	Vector graphics editor
Python	3.6+	Extension runtime
Internet	-	API access (except Ollama)

Optional for Local Generation

Component	Purpose
Ollama	Run AI models locally without API costs

🚀 Installation

Step 1: Locate Extensions Directory

OS	Path
Windows	`C:\Users\[YourName]\AppData\Roaming\inkscape\extensions\`
macOS	`~/Library/Application Support/org.inkscape.Inkscape/config/inkscape/extensions/`
Linux	`~/.config/inkscape/extensions/`

💡 Tip: In Inkscape: Edit → Preferences → System shows extensions path

Step 2: Install Extension Files

Create extension folder:

mkdir -p [extensions-directory]/svg_maker

Copy files:

cp svg_llm.py [extensions-directory]/svg_maker/
cp svg_llm.inx [extensions-directory]/svg_maker/

Restart Inkscape

Step 3: Verify Installation

Open Inkscape
Go to Extensions → Generate → SVG LLM Generator
The extension dialog should appear

🎯 Quick Start

Basic Example

Open Inkscape
Go to Extensions → Generate → SVG LLM Generator
Select a provider (e.g., OpenAI)
Enter your API key
Type a prompt: A simple house icon with a chimney
Click Apply

Result: An AI-generated SVG house icon appears on your canvas!

📖 Usage Guide

Tab Overview

Tab	Purpose
Provider	Select AI provider and enter API key
Prompt	Enter description and select presets
Style	Configure visual style and colors
Size	Set dimensions and aspect ratio
Output	Grouping, positioning, variations
Advanced	Temperature, tokens, retries, seed
Help	Quick reference and tips

Prompt Tab Options

Option	Description
Prompt	Text description of desired SVG
Preset	Quick templates (icon, logo, diagram, etc.)
Use Selection Context	Match style of selected elements

Style Tab Options

Option	Values	Description
Style Hint	minimal, detailed, flat, outline, geometric, organic, hand_drawn, isometric, cartoon	Visual style
Color Scheme	any, monochrome, warm, cool, pastel, vibrant, grayscale, earth, neon	Color palette
Complexity	simple, medium, complex	Detail level
Stroke Style	any, thin, medium, thick, none	Line thickness

Size Tab Options

Option	Values
Size	small (200px), medium (400px), large (600px), xlarge (800px), custom
Aspect Ratio	square, landscape (4:3), portrait (3:4), widescreen (16:9), banner (3:1)
Custom Width/Height	Any pixel value

Output Tab Options

Option	Description
Add Group	Wrap generated SVG in a group
Group Name	Custom identifier for the group
Position	center, origin (0,0), selection (next to selected)
Variations	Generate 1-4 different interpretations
Include Gradients	Allow gradient fills
Include Animations	Add CSS/SMIL animations
Add Accessibility	Include title/desc elements

⚙️ Configuration

API Key Management

Three ways to provide API keys (in priority order):

1. Direct Input (Temporary)

Enter key directly in the Provider tab each time.

2. Save for Future Use (Recommended)

Enter API key in Provider tab
Check "Save API key"
Key is stored in .config.json

3. Config File (Manual)

Edit .config.json in the extension directory:

{
    "api_keys": {
        "openai": "sk-your-openai-key",
        "anthropic": "sk-ant-your-anthropic-key",
        "google": "your-google-api-key"
    },
    "last_provider": "openai"
}

Prompt History

The extension automatically saves your prompts to .svg_llm_history.json:

[
    {
        "prompt": "A simple house icon",
        "timestamp": "2024-01-15T10:30:00",
        "width": 400,
        "height": 400,
        "provider": "openai",
        "model": "gpt-4-turbo",
        "style": "minimal",
        "color_scheme": "any"
    }
]

🔌 Provider Setup

OpenAI

Get API key from platform.openai.com/api-keys
Select provider: openai
Recommended models: gpt-4-turbo, gpt-4o, gpt-3.5-turbo

Anthropic Claude

Get API key from console.anthropic.com
Select provider: anthropic
Recommended models: claude-3-5-sonnet-20241022, claude-3-opus-20240229

Google Gemini

Get API key from aistudio.google.com/apikey
Select provider: google
Recommended models: gemini-1.5-flash, gemini-1.5-pro

Ollama (Local)

Install Ollama from ollama.com
Pull a model:
```
ollama pull llama3.1
```
Start Ollama:
```
ollama serve
```
Select provider: ollama
No API key needed!

🔧 Customization

Changing Default Settings

Edit the class constants in svg_llm.py:

class SVGLLMGenerator(inkex.EffectExtension):
    CONFIG_FILENAME = '.config.json'      # Config file name
    HISTORY_FILENAME = '.svg_llm_history.json'  # History file name
    MAX_HISTORY = 50                       # Max history entries

Adding Custom Presets

Add new presets in the build_prompt method:

preset_prompts = {
    'icon': "Create a simple, recognizable icon...",
    'illustration': "Create an artistic illustration...",
    # Add your custom preset:
    'scientific': "Create a scientific diagram with labels and annotations...",
}

Custom Style Descriptions

Modify style descriptions in build_prompt:

style_descriptions = {
    'minimal': 'Use a minimal, clean design...',
    # Add custom style:
    'blueprint': 'Use technical blueprint style with white lines on blue background...',
}

Custom Color Schemes

Add color schemes in build_prompt:

color_descriptions = {
    'monochrome': 'Use only one color...',
    # Add custom scheme:
    'synthwave': 'Use synthwave/retrowave colors (pink, cyan, purple on dark)...',
}

Modifying the System Prompt

Edit the system message in API call methods:

def call_openai_api(self, prompt, api_key):
    # ...
    data = {
        'messages': [
            {
                'role': 'system',
                'content': 'Your custom system prompt here...'
            },
            # ...
        ]
    }

🐛 Troubleshooting

Common Issues

Extension not appearing in menu

Solutions:

Verify files are correctly placed:

ls [extensions-directory]/svg_maker/
# Should show: svg_llm.py, svg_llm.inx

Check file permissions (Linux/macOS):
```
chmod +x svg_llm.py
```
Restart Inkscape completely
Check Inkscape error log: Edit → Preferences → System → Open Error Log

API Key Error

Error: Please provide a valid API key for [provider]

Solutions:

Verify API key is correct (no extra spaces)
Check API key has proper permissions
Ensure API key is not expired
For Ollama: No key needed, ensure server is running

Network/Connection Error

Error: Network Error: ...

Solutions:

Check internet connection
Verify firewall isn't blocking requests
For Ollama: Ensure ollama serve is running
Try increasing timeout in Advanced tab

Invalid SVG Generated

Error: Failed to parse SVG code: ...

Solutions:

Try a different model (GPT-4 tends to be more reliable)
Simplify your prompt
Reduce complexity setting
Enable "Optimize paths" option
Try with a different provider

Ollama Connection Failed

Error: Cannot connect to Ollama

Solutions:

Start Ollama server:
```
ollama serve
```
Verify Ollama is running:
```
curl http://localhost:11434/api/tags
```
Check custom endpoint URL if not using default
Pull a model if none installed:
```
ollama pull llama3.1
```

Debug Tips

Check error log: Edit → Preferences → System → Open Error Log
Test API independently: Use curl or Postman to verify API access
Start simple: Test with basic prompts before complex ones
Check history: Review .svg_llm_history.json for past successful prompts

📁 File Structure

svg_maker/
├── svg_llm.py              # Main extension code
├── svg_llm.inx             # Inkscape extension definition
├── README.md               # This file
├── LICENSE                 # MIT License
├── .config.json            # Saved API keys (auto-created)
└── .svg_llm_history.json   # Prompt history (auto-created)

💡 Tips & Best Practices

Prompt Writing Tips

Be specific: "A red apple with a leaf" > "an apple"
Mention style: "flat design icon of..." or "detailed illustration of..."
Specify colors: "using blue and orange colors"
Define complexity: "simple/minimal" or "detailed/intricate"

Performance Tips

Use presets: They include optimized instructions
Start with medium complexity: Adjust based on results
Lower temperature for consistency: 0.3-0.5 for predictable results
Higher temperature for creativity: 0.8-1.0 for variety

Quality Tips

GPT-4 models produce best SVG: More reliable than GPT-3.5
Claude excels at complex diagrams: Good for flowcharts
Gemini is fast and affordable: Good for simple icons
Local Ollama varies by model: llama3.1 recommended

🤝 Contributing

Contributions are welcome!

Fork the repository
Create a feature branch (git checkout -b feature/new-provider)
Commit changes (git commit -m 'Add new AI provider')
Push to branch (git push origin feature/new-provider)
Open a Pull Request

Development Setup:

git clone https://github.com/YouvenZ/svg_maker_ink.git
cd svg_maker_ink
# Symlink for testing
ln -s $(pwd) ~/.config/inkscape/extensions/svg_maker

📄 License

This project is licensed under the MIT License - see LICENSE file for details.

📧 Support

Issues: GitHub Issues
Discussions: GitHub Discussions
Email: youvenz.pro@gmail.com

🙏 Acknowledgments

Built on Inkscape Extension API
Powered by OpenAI, Anthropic, Google, and Ollama
Inspired by the need for AI-assisted vector graphics creation

🔄 Changelog

v1.0.0 (2024)

✨ Initial release
✅ OpenAI, Anthropic, Google, Ollama support
✅ Multiple style and color options
✅ Flexible sizing with aspect ratios
✅ Selection context awareness
✅ Multiple variations generation
✅ Prompt history tracking
✅ API key persistence
✅ Retry logic for reliability

Name		Name	Last commit message	Last commit date
Latest commit History 57 Commits
prompts		prompts
.gitignore		.gitignore
.svg_llm_history.json		.svg_llm_history.json
README.md		README.md
example_config.json		example_config.json
license		license
svg_llm.inx		svg_llm.inx
svg_llm.py		svg_llm.py
svg_llm_anthropic.py		svg_llm_anthropic.py
svg_llm_azure.py		svg_llm_azure.py
svg_llm_custom.py		svg_llm_custom.py
svg_llm_dialog.py		svg_llm_dialog.py
svg_llm_google.py		svg_llm_google.py
svg_llm_history.json		svg_llm_history.json
svg_llm_ollama.py		svg_llm_ollama.py
svg_llm_openai.py		svg_llm_openai.py
svg_llm_prompts.py		svg_llm_prompts.py
test_svg_generation.py		test_svg_generation.py

Folders and files

Latest commit

History

Repository files navigation

SVG LLM Generator for Inkscape

📺 Demo

📋 Table of Contents

✨ Features

📦 Requirements

Optional for Local Generation

🚀 Installation

Step 1: Locate Extensions Directory

Step 2: Install Extension Files

Step 3: Verify Installation

🎯 Quick Start

Basic Example

📖 Usage Guide

Tab Overview

Prompt Tab Options

Style Tab Options

Size Tab Options

Output Tab Options

⚙️ Configuration

API Key Management

1. Direct Input (Temporary)

2. Save for Future Use (Recommended)

3. Config File (Manual)

Prompt History

🔌 Provider Setup

OpenAI

Anthropic Claude

Google Gemini

Ollama (Local)

🔧 Customization

Changing Default Settings

Adding Custom Presets

Custom Style Descriptions

Custom Color Schemes

Modifying the System Prompt

🐛 Troubleshooting

Common Issues

Debug Tips

📁 File Structure

💡 Tips & Best Practices

Prompt Writing Tips

Performance Tips

Quality Tips

🤝 Contributing

📄 License

📧 Support

🙏 Acknowledgments

🔄 Changelog

v1.0.0 (2024)

About

Topics

Resources

License

Uh oh!

Stars

Watchers

Forks

Releases

Packages 0

Uh oh!

Contributors

Uh oh!

Languages

Packages
