[hlth] Fix false HLTH SWR warnings during transmit transitions

[jensenpat]

Summary

• qualify HLTH SWR scoring with fresh instantaneous forward power instead of the slowly decaying display-power value
• require a full five-update SWR admission window and use its lower quartile, rejecting isolated reflected-power-floor spikes while preserving sustained mismatch warnings
• add a deterministic health_applet_test covering key-up, unkey, intermittent low-power outliers, healthy load, and sustained high SWR

Root cause

HLTH combined MeterModel's smoothed forward-power value with unsmoothed SWR reports, then retained each report in its 3.5-second variance history. Near key/unkey—and especially at low forward power—the radio can emit isolated upward SWR samples even though the current main meter is normal. Those samples poisoned HLTH's baseline and variance score, producing a stale WATCH or GROUND? state.

The bridge trace on the ANT2 dummy load at a 2 W setpoint observed instantaneous SWR reports as high as 1.79 among predominantly 1.00 readings. The fix admits only distinct, power-qualified reports and requires four of the latest five reports to be elevated before scoring the rise.

Verification

• cmake --build build --target health_applet_test AetherSDR -j8
• ctest --test-dir build -R 'health_applet_test|meter_model_test' --output-on-failure — 2/2 passed
• python3 tools/check_a11y.py — no new findings (existing baseline warnings only)
• python3 tools/check_engine_boundary.py --strict — 0 blockers
• git diff --check

Agent automation bridge proof on the rebuilt app:

• live TX antenna readback: ANT2
• hard automation power ceiling: 2 W; Tune power and RF power both read back as 2 W
• before: transmitter off, HLTH IDLE, SWR 1.00
• keyed steady state: 1.34 W instantaneous forward power, live SWR 1.27, HLTH OK
• after unkey: transmitter off, HLTH returned to IDLE
• restored afterward: ANT1, Tune power 10 W, RF power 40 W, ATU memory recall successful, HLTH hidden

Fixes #4243

👨🏼‍💻 Generated with OpenAI Codex (GPT-5.6 Sol) and tested by @jensenpat

[aethersdr-agent]

Nicely scoped fix with a clear root-cause writeup. I traced the data flow and the design holds: directionalPowerMetersChanged carries m_fwdPowerInstant (raw instantaneous forward power) and is emitted right after txMetersChanged from the same MeterModel, so updateRadioDirectionalMeters reliably overwrites swrQualifyingPowerWatts with the instantaneous value. That makes the unkey case behave — m_fwdPower is still decaying ≥0.75 W while m_fwdPowerInstant≈0, so the SWR sample fails kActivePowerWatts qualification and never poisons the baseline. The admittedSwr lower-quartile (index (n-1)/4 = 1 at n=5) does require 4 of 5 elevated samples as claimed, and severity is correctly forced to 0 until swrTrusted. No null-deref, leak, QSettings, or RAII concerns, and all 7 checks are green. The health_applet_test covering key-up / unkey / outliers / sustained-fault is a welcome addition.

Polish (non-blocking)

• The new tests wait on wall-clock elapsed time and the 50 ms GUI tick timer — inherently timing-sensitive under CI load. It passed here, so this is just a heads-up on the pattern, not a request to change it.

Non-blocking notes

• admittedSwr's comment hardcodes "four of five" / "250 ms"; those numbers are only exact at the current kSwrAdmissionWindow/kSwrSettleFrames/kTickMs. Consider phrasing it in terms of the constants so it doesn't drift if they're tuned later.

Thanks for the thorough live-bridge proof and the deterministic test — looks good to me.

---

_{🤖 aethersdr-agent · cost: $7.0732 · model: claude-opus-4-8}

[NF0T]

Good root-cause diagnosis and a well-designed core idea — decoupling instantaneous forward power (for SWR gating) from the smoothed display power is the right direction, and the four new tests demonstrate the false-positive fix works for the reported case. CI is green and the commit is signed.

Two issues that make this riskier than the bug it fixes:

1. The admission-window reset can permanently trap HLTH in "never trusted," masking a real sustained fault. m_swrAdmissionWindow clears on any single inactive tick or source switch — unlike every other piece of state in this class, which tolerates up to 24 frames (~1.2s) before resetting. bestSnapshot() recomputes the winning meter source every tick from two freshness thresholds (900ms/1700ms) with no hysteresis; if an amplifier or tuner's meter cadence straddles that boundary, bestSnapshot() can oscillate between sources, clearing the 5-sample window each time. Once trapped in that oscillation, swrTrusted never becomes true and sample.severity stays forced to 0.0f — even during a genuine antenna fault. That's the opposite of what #4243 needs. None of the four new tests exercise more than one meter source, so this wouldn't be caught. Would suggest either not clearing the window on a bare source switch (only on genuine inactivity), or giving it the same dropout tolerance the rest of the class already has.

2. The fix's correctness depends on an undocumented, and not-always-true, cross-signal assumption. directionalPowerMetersChanged and txMetersChanged both emit from MeterModel::updateValues(), but directionalChanged is gated by three branches (FWDPWR/REFPWR/SWR) while txChanged is gated by two (FWDPWR/SWR) — so a REFPWR-only packet fires directionalPowerMetersChanged alone, with no txMetersChanged in the same cycle, on any radio that reports REFPWR. It's harmless today only because the timestamps happen to reflect staleness correctly in that case, but nothing in HealthApplet.cpp comments this dependency — a future MeterModel.cpp refactor (splitting FWDPWR/SWR into independently-gated signals, a plausible cleanup) could silently reintroduce the exact bug this PR fixes, with no compile error and no guaranteed test failure. Worth at least a comment at the connection site explaining why emission order matters here.

Also worth addressing, lower priority:

• The swrTrusted gate (4-frame settle + 5-sample quorum, ~200-250ms+) applies uniformly to all three meter sources, but the root cause — smoothed power gating unsmoothed SWR — only exists for Radio (MeterModel.cpp confirms Tuner/Amplifier forward power is never smoothed). This adds an unnecessary detection delay for a genuine Tuner/Amplifier fault that previously flagged immediately. Untested by the new suite (Radio-source meters only).
• pushRecent()/baseline-averaging is now gated behind swrTrusted, not just active — health telemetry freezes for the first ~250ms+ of every TX over, so a fast real fault confined to that window is invisible once per over, systematically.

Non-blocking:

• admittedSwr() re-implements a sort-based order-statistic pattern that exists as nth_element-based helpers in 4+ other files (AdaptiveFilterEngine.cpp even documents a prior review making this exact tradeoff) — worth reusing one of those instead.
• cacheMeters()'s writes to the new "qualifying" fields are dead code for Radio (immediately overwritten) and redundant for Tuner/Amp (duplicate the already-instantaneous value) — a comment explaining the asymmetry would help the next reader.

Happy to re-review once the admission-window fragility and the cross-signal dependency are addressed — the core approach is sound, it just needs to fail safer.

[ten9876]

Maintainer approval (Tier 1) — @NF0T's issues fixed, fail-safe

Full high-effort pass. I independently confirmed NF0T's #1 is a real fail-unsafe trap: bestSnapshot() has no hysteresis at its 900ms/1700ms boundary (verified in code), so a second meter cadence straddling it oscillates the source and the old m_swrAdmissionWindow.clear() on every flip could pin swrTrusted false and force severity to 0 during a genuine fault. Pushed 7d4bdbf5 to resolve all of it:

• #1 (admission-window fragility): the window now tolerates kSwrDropoutFrames (~1.2s, matching the class's idle-baseline tolerance) of inactivity or source mismatch before resetting, admits only samples from the tracked source, and still acquires the first source immediately. The change is fail-safe by construction — it can only make the window persist longer (more trust → more detection), never shorter.
• #3 (Tuner/Amp settle delay): only Radio forward power is smoothed, so Tuner/Amplifier now trust raw SWR immediately — no ~250ms delay before a real amp/tuner fault flags.
• #2 / #4: documented the directionalPowerMetersChanged/txMetersChanged co-emission dependency at the connect site, and the intentional Radio settle blind spot.
• Non-blocking: admittedSwr() → std::nth_element (O(n)); cacheMeters asymmetry documented; unkey-test margin widened for CI headroom.

Verification: health_applet_test 4/4 across 10 runs, full app builds clean. Notably, my first cut of the tolerance delayed first-source acquisition by 24 frames and masked the sustained-fault test — I caught and fixed it, so the suite genuinely has teeth against the fail-unsafe direction.

Honest coverage note: I did not add a dedicated multi-source oscillation test — reproducing the 900ms-straddle deterministically in the current wall-clock harness would be flaky (the exact concern behind NF0T's test note), and a flaky test is worse than none. The fix is instead validated by the fail-safe reasoning above + the regression I caught. A clock-injection test seam is a reasonable follow-up.

Approving. Thanks for the sharp fail-unsafe catch, @NF0T, and the solid root-cause work, @jensenpat.

Requested changes have been made
