Real-Time Speech Translation System

Real-time speech translation system for online conference scenarios. The project captures live speech, detects speech segments, transcribes them, translates the text, synthesizes translated audio, and displays latency metrics through a browser-based interface.

Bachelor thesis context: real-time / near-real-time speech translation during online conferences.

Overview

This project implements a modular speech translation pipeline:

Audio input -> VAD -> STT -> MT -> TTS -> translated audio + subtitles

The system is designed around open-source models and local execution, with special attention to Apple Silicon performance. It uses FastAPI and WebSockets for the backend streaming layer, a browser UI for interaction and visualization, and swappable model backends for transcription, translation, and speech synthesis.

Demo

Features

Feature	Details
Live audio pipeline	Captures microphone audio, processes speech segments, and streams translation results.
Speech-to-text	Uses Faster-Whisper for transcription.
Machine translation	Uses CTranslate2-optimized Opus-MT models, with NLLB-200 as a fallback path.
Text-to-speech	Supports Piper TTS, XTTS, OmniVoice, and MLX-Audio/Qwen3-TTS experiments.
Voice activity detection	Uses WebRTC VAD and RMS pre-filtering to reduce unnecessary STT calls.
Dynamic language switching	Allows changing source and target languages from the UI.
Speaker voice profiles	Supports recording, uploading, renaming, deleting, and using speaker reference audio.
Latency visualization	Displays latency breakdown and timeline charts in the browser UI.
Local-first research setup	Focuses on open-source models and local hardware constraints.

System design

flowchart TB
    Speaker([Speaker]) --> Browser[Browser UI]
    Browser --> WebSocket[WebSocket Audio Stream]

    WebSocket --> Backend[FastAPI Backend]
    Backend --> VAD[Voice Activity Detection]
    VAD --> STT[Faster-Whisper STT]
    STT --> MT[CTranslate2 / NLLB Translation]
    MT --> TTS[Piper / XTTS / OmniVoice / MLX TTS]

    TTS --> Playback[Translated Audio Playback]
    MT --> Subtitles[Translated Text + Subtitles]
    Backend --> Metrics[Latency Metrics]
    Browser --> Voices[Speaker Voice Profiles]
    Voices --> TTS

    Backend --> DB[(SQLite / Local Metadata)]
    Metrics --> Browser
    Playback --> Browser
    Subtitles --> Browser

    classDef actor fill:#DBEAFE,stroke:#2563EB,color:#0F172A,stroke-width:1px
    classDef client fill:#EDE9FE,stroke:#7C3AED,color:#0F172A,stroke-width:1px
    classDef transport fill:#CCFBF1,stroke:#0F766E,color:#0F172A,stroke-width:1px
    classDef model fill:#FEF3C7,stroke:#D97706,color:#0F172A,stroke-width:1px
    classDef output fill:#DCFCE7,stroke:#16A34A,color:#0F172A,stroke-width:1px
    classDef data fill:#FCE7F3,stroke:#DB2777,color:#0F172A,stroke-width:1px

    class Speaker actor
    class Browser,Voices client
    class WebSocket,Backend,VAD transport
    class STT,MT,TTS model
    class Playback,Subtitles,Metrics output
    class DB data

Loading

Runtime flow

Step	Component	Responsibility
1	Browser UI	Captures microphone audio and sends chunks over WebSocket.
2	FastAPI backend	Manages sessions, model initialization, WebSocket connections, and API routes.
3	VAD layer	Filters silence and detects valid speech segments.
4	STT layer	Transcribes speech with Faster-Whisper.
5	MT layer	Translates recognized text using CTranslate2 Opus-MT or fallback translation models.
6	TTS layer	Synthesizes translated speech through the selected TTS backend.
7	UI output	Plays translated audio, displays transcription/translation, and visualizes latency.

Tech stack

Layer	Choice	Notes
Backend	FastAPI, Uvicorn, WebSockets	Streaming API and browser communication.
Frontend	HTML, CSS, JavaScript	Browser UI for capture, playback, language selection, and metrics.
STT	Faster-Whisper	Efficient Whisper inference for transcription.
MT	CTranslate2 Opus-MT, NLLB-200	Local machine translation with multilingual fallback.
TTS	Piper TTS, XTTS, OmniVoice, MLX-Audio/Qwen3-TTS	Fast synthesis and voice cloning experiments.
VAD	WebRTC VAD	Speech segment detection.
Audio processing	soundfile, librosa, pydub, FFmpeg	Audio loading, conversion, and processing utilities.
Metrics	Chart.js, matplotlib, seaborn	Latency visualization and analysis.
Database/auth	SQLAlchemy, Alembic, python-jose, argon2	Local metadata, user handling, and auth experiments.
Testing	pytest, pytest-asyncio, Playwright	Backend and UI test support.

Model backends

Stage	Backend	Purpose
STT	Faster-Whisper	Transcribes source speech into text.
MT	CTranslate2 Opus-MT	Fast translation for supported language pairs.
MT fallback	NLLB-200	Fallback for lower-resource or unsupported language pairs.
TTS	Piper	Fast non-cloning speech synthesis.
TTS	XTTS	CPU-based zero-shot voice cloning.
TTS	OmniVoice	Higher-quality voice cloning; real-time mainly with NVIDIA GPU.
TTS	MLX-Audio/Qwen3-TTS	Apple Silicon voice cloning research path.

Performance focus

The project targets low-latency local execution:

Pipeline mode	Target / observed direction
Standard translation	Target under ~1.5 seconds end-to-end.
Piper TTS	Very low synthesis latency, around ~0.1 seconds in local notes.
XTTS voice cloning	Slower CPU voice cloning path, around ~2–5 seconds.
OmniVoice	Stronger with NVIDIA GPU; CPU/MPS can be too slow for real time.
MLX-Audio/Qwen3-TTS	Apple Silicon optimization path for real-time voice cloning.

Quick start

Prerequisites

• Python 3.9+
• Git
• FFmpeg
• BlackHole 2ch or a similar virtual audio device on macOS for audio routing tests

On macOS:

brew install ffmpeg blackhole-2ch

Windows setup

Run the provided PowerShell setup script:

.\setup_windows.ps1

The script installs Python, FFmpeg, Node.js, creates a virtual environment, and installs dependencies.

macOS / Linux setup

Clone the repository:

git clone https://github.com/brusnyak/bp.git
cd bp

Create and activate a virtual environment:

python3 -m venv venv
source venv/bin/activate

Install dependencies:

pip install -r requirements.txt

Generate local HTTPS certificates:

openssl req -x509 -newkey rsa:4096 -nodes \
  -out certs/cert.pem \
  -keyout certs/key.pem \
  -days 365 \
  -subj "/CN=localhost"

Run the application:

python app.py

Open:

https://localhost:8000

Your browser may ask you to accept the self-signed certificate.

Model setup

Piper TTS

Piper models can be downloaded manually:

python backend/tts/download_piper_models.py en_US-ryan-medium
python backend/tts/download_piper_models.py sk_SK-lili-medium
python backend/tts/download_piper_models.py cs_CZ-jirka-medium

CTranslate2 translation models

Convert Opus-MT models to CTranslate2 format:

python backend/mt/convert_opus_mt_to_ct2.py --model_name Helsinki-NLP/opus-mt-en-sk
python backend/mt/convert_opus_mt_to_ct2.py --model_name Helsinki-NLP/opus-mt-sk-en
python backend/mt/convert_opus_mt_to_ct2.py --model_name Helsinki-NLP/opus-mt-en-cs

Faster-Whisper

The Faster-Whisper model is downloaded automatically on first use.

Voice cloning models

XTTS, OmniVoice, and MLX-Audio models are downloaded automatically when selected, depending on backend support and local hardware.

Usage

1. Open https://localhost:8000.
2. Initialize the pipeline.
3. Select source and target languages.
4. Choose the TTS backend.
5. Optionally upload or record a speaker voice sample for voice cloning.
6. Speak into the microphone.
7. Monitor transcription, translation, playback, and latency charts.

Testing

Run the streaming pipeline tests:

python test/streaming_pipeline_tests.py

For full evaluation, add test audio files to the test/ directory:

File	Purpose
test/My test speech_xtts_speaker_clean.wav	English speech test input.
test/slovak_test_speech.wav	Slovak speech test input.
test/Voice-Training.wav	Speaker reference audio for voice cloning.

Matching transcript and translation reference files should be added for metric-based evaluation.

Project structure

bp/
├── app.py               # FastAPI app, WebSocket server, UI mounting
├── backend/
│   ├── main.py          # Model orchestration, routes, sessions, pipeline config
│   ├── stt/             # Faster-Whisper wrapper
│   ├── mt/              # Translation backends and model conversion scripts
│   ├── tts/             # Piper, XTTS, OmniVoice, and hybrid TTS modules
│   └── utils/           # Audio, auth, and database utilities
├── ui/                  # Browser interface
├── test/                # Streaming and pipeline tests
├── speaker_voices/      # Local speaker reference audio and metadata
├── documentation/       # Thesis notes and supporting research
├── requirements.txt
└── package.json

Current development status

Area	Status
Piper TTS	Integrated as the fast non-cloning synthesis backend.
XTTS	Integrated for CPU-based voice cloning.
OmniVoice	Integrated but best suited to NVIDIA GPU for real-time use.
MLX-Audio/Qwen3-TTS	Identified as the Apple Silicon optimization path.
Hybrid MT	CTranslate2 Opus-MT with NLLB fallback added.
UI and backend fixes	Audio processing, voice selection, and speaker profile handling improved.
Thesis alignment	Conference use case and latency benchmarking remain the key academic framing.

Roadmap

• Replace or supplement OmniVoice with MLX-Audio for Mac builds.
• Benchmark Qwen3-TTS on M1 Pro hardware for real-time voice cloning.
• Improve multi-speaker handling for conference scenarios.
• Expand evaluation with consistent Slovak/English test audio.
• Package the system for simpler installation.
• Refine thesis documentation around methodology, measurements, and limitations.

README style direction

This repository follows the shared portfolio README structure:

• Short project description at the top.
• Technology labels for fast scanning.
• Coloured system design diagram when architecture is useful.
• Structured features, model backends, testing, and roadmap tables.
• Practical setup instructions separated from research/development notes.
