Mang's Intro to IM - Week 1-7 Lecture Notes

Week 1-7 lecture notes

Week 8-14 lecture notes

p5js Example Sketches

Weekly Schedule

  • Week 1 - Introductions, p5.js
  • Week 2 - Variables, Animation, Conditionals
  • Week 3 - Functions, Arrays, Object-Oriented Programming (OOP)
  • Week 4 - Tool training, Working with text
  • Week 5 - Working with Pixels, Sound
  • Week 6 - Computer Vision
  • Week 7 - Midterm presentations
  • FALL BREAK
  • Week 8 - Introduction to Arduino, electricity
  • Week 9 - Analog and digital I/O
  • Week 10 - Sound, movement, circuit schematics
  • Week 11 - Serial Communication, Connecting Arduino to p5.js
  • Week 12 - Motors, Soldering, Fabrication
  • Week 13 - Circuit debugging
  • Week 14 - National Day, Final project work session
  • Week 15 - Final project presentations, show setup
  • IM Show - IM End of Semester Show

Week 1

Week 1.1 - 8/26

Class starts!

What’s the class about?

  • Digital computation beyond computers (sometimes called "physical computing") considering humanistic needs in design and usability
  • Computers traditionally lacked knowledge of outside world beyond a keyboard, mouse
  • Look critically at products and designs
  • As artists and designers, we can explore new paradigms of interaction with machines and each other
  • Relatively easily and inexpensively explore creative computation through open source software and hardware
  • No background needed, strong DIY attitude
  • Low barrier to entry, high ceiling

Red Burns advice to new students

Let's Stop Focusing on Shiny Gadgets and Start Using Tech to Empower People

What I hope for you:

That you combine that edgy mixture of self-confidence and doubt.

That you have enough self-confidence to try new things.

That you have enough self doubt to question.

That you think of technology as a verb, not a noun; it is subtle but important difference.

That you remember the issues are usually not technical.

That you create opportunities to improvise.

That you provoke it. That you expect it.

That you make visible what, without you, might never have been seen.

That you communicate emotion.

That you create images that might take a writer ten pages to write.

That you observe, imagine and create.

That you look for the question, not the solution.

That you are not seduced by speed and power.

That you don’t see the world as a market, but rather a place that people live in -- you are designing for people, not machines.

That you have a stake in magic and mystery and art.

That sometimes we fall back on Rousseau and separate mind from body.

That you understand the value of pictures, words, and critical thinking.

That poetry drives you, not hardware.

That you are willing to risk, make mistakes, and learn from failure.

That you develop a practice founded in critical reflection.

That you build a bridge between theory and practice.

That you embrace the unexpected.

That you value serendipity.

That you reinvent and re-imagine.

That you listen. That you ask questions. That you speculate and experiment.

That you play. That you are spontaneous. That you collaborate.

That you welcome students from other parts of the world and understand we don’t live in a monolithic world.

That each day is magic for you.

That you turn your thinking upside down.

That you make whole pieces out of disparate parts.

That you find what makes the difference.

That your curiosity knows no bounds.

That you understand what looks easy is hard.

That you imagine and re-imagine.

That you develop a moral compass.

That you welcome loners, cellists, and poets.

That you are flexible. That you are open.

That you can laugh at yourself. That you are kind.

Examples

Homework

Week 1.2 - 8/28

Let's get started

Simple shapes in p5.js

Open p5.js editor

  • ellipse()
  • rect()
  • createCanvas()
  • triangle(x1, y1, x2, y2, x3, y3)
  • line()
  • point()

What does this all mean?

  • Functions
  • Arguments or parameters

Controlling color, fill, and stroke

  • stroke()
  • noStroke()
  • fill()
  • arc(100, 100, 100, 100, 0, 180)
  • arc(100, 100, 100, 100, 0, radians(180), CHORD)

Here is the program we developed in class:

function setup() {
  createCanvas(600,600);
  background(25, 130, 80);

  // draw a circle and a rectangle with the default colors
  circle (width/2, height/2, 50);
  rect(10, 10, 80, 20);

  // change the stroke and fill
  fill(180,0,0);
  stroke(0,0,180);
  // circle(80, 80, 80); this circle is commented out so it won't be drawn
  ellipse(200, 280, 50, 80);

  // change the stroke color but keep the same fill
  stroke(180,0,0);
  line( 0,0, 300, 100);

  let foo = radians(90);
  print(foo);                  //!!!!!!!!!!!!!!!!!!!!!!!! THIS IS VERY USEFUL!!!!!!!

  arc(50, 55, // center of the ellipse
      50, 50, // width and height
      0, radians(180)); // start and stop angle

  triangle( 100, 100, 10, 200, 100, 300);
  print(width/2, height/2);
}

let x = 0;
function draw() {
	// Where am I?
  print(mouseX, mouseY);

	// I can do animation!
  circle(x, 500, 40);
  x=x+1;
}

Notes

  • Built-in variables
    • width, height, mouseX, mouseY
    • many others; we will discover more as we go along

Create an account on p5js.org so you can save your sketches! Sketches will be submitted by making a blog post and submitting through Brightspace (in future weeks)

Sharing your sketch

Back to top

Week 2

Week 2.1 - 9/2

Questions

Did any questions come up since we last met?

Variables

p5.js Links

  • Variables

  • True and False

  • Variable Scope

  • Array

  • Mouse Functions

    • Example of storing a value in a variable

  • Javascript is not a typed language: you don't need to declare a variable's type

  • Week 2 - Variables (p5js editor)

  • let myNumber = 4.5;

  • let myString = "the quick brown fox";

  • let myArray = ["the", "quick", "brown", "fox"];

  • let myRandomNumber = random(255);

  • let myRandomNumber = round(random(255)); How can we find out what a variable's value is? print()

Animation

p5.js Links

Use the draw() function to draw something different in each frame. This can be the location of a shape but you can manipulate anything such as color also:

The draw() function is called once per frame. Think of it as drawing a new page on a "flip book"

Week 2 - Drawing (p5js editor)

let foo = 0;

function setup() {
  createCanvas(300, 300);
}

function draw() {
  ellipse(foo, 50, 40, 40);
  foo = foo + 1;
}

By default, the previous frame is not erased. Sometimes this is useful. Use the background() function to "paint" over any previous drawings.

function setup() {
  createCanvas(500, 500);
}

let triangleTopLeftX = 0;
let redValue = 255;

function draw() {
  // erase previous drawings
  background(10, 255, 255);

  // Move the triangle
  triangleTopLeftX = triangleTopLeftX + 1;

	// If the triangle reaches the right edge, move to the left edge
  if (triangleTopLeftX >= width) {
    triangleTopLeftX = 0;
  }

  // Change the value of red
  redValue = redValue - 1;

	//If red reaches a certian level, reset it
  if (redValue === 55) {
		redValue = 255;
	}

  // Select the fill for the triangle
  fill(redValue, redValue - 100, redValue - 100);

  // Draw the triangle
  triangle(
    triangleTopLeftX,
    20, // top left corner
    triangleTopLeftX + 100,
    30, // top right corner
    triangleTopLeftX + 50,
    200
  ); // bottom corner

  // Select the fill for the circle
  fill(10,20, 240);

  // Draw the circle
  circle(mouseX, mouseY, 30);
  print("mouse coordinates = " + mouseX + ", " + mouseY);
}
Notes:
  • Local vs. Global variables
  • Built-in variables
// Example usage of a global variable

let count; // this is now a global variable

function setup() {
  circle(50, 50, 30);
  count = 7; // the variable is initialized here
}

function draw() {
  count = count + 1; // not algebra!
  // The result of the right hand side calculation
  // replaces whatever value was stored in the variable
  // on the left side of the '=' sign
  // end result: the variable "count" is incremented by 1

  print (count);
}
What is frameRate()?
function setup() {
  frameRate(10);       // frameRate() is a function
  print(frameRate()); // it takes awhile for the frame rate to change
}

function draw() {
  print(frameRate());
}
Additional resources

Refer to these for additional information

Week 2.2 - 9/4

Overview:

  • Readings
  • Review
  • Loops
  • Functions
  • Homework assignment + reading
Readings

Each week there will be assigned reading. You need to read / watch the material before the start of Monday's class and post a response. We will discuss the readings in groups in class.

Explanation of in-class discussion (Syllabus)

Week 2 - Random shuffle group (p5js) - Choosing discussion groups

List of readings (Weekly Schedule)

Review
  • conditionals
function setup() {
  createCanvas(300, 300);
}

function draw() {
  if (mouseIsPressed === true) {
    background(color(0, 0, 255));
  } else {
    background(color(200, 0, 0));
  }
}

Notes:

  1. mouseIsPressed is another built-in variable. There are many others.
  2. mouseIsPressed is a new type of data, namely a boolean, which means it has only one of two values, true or false
  3. Note that { and } indicate the blocks
  4. The else part of an if() statement is optional (what happens if we remove it?)

In class exercise:

  • Using the cursor to draw
  • Now use a mouse press to clear the screen
  • Clear the screen if the mouse is pressed inside a certain circle
  • Combine these to create a primitive painting program
Loops

while() is like if() but it keeps on doing it as long as condition is true

function setup() {
  createCanvas(300, 300);

  let foo = 50; // create and initialize a variable

  while (foo < width) { // keep going as long as the condition is true
    ellipse(foo, 50, 40, 40);
		// modify the variable so something different happens next time
    foo = foo + 50;
  }
}
  1. You should get in the habit of giving meaningful names to your variables.
    1. What is a better name for the variable foo?
  2. What would happen if you replace the while() with if()?

There is another way to make a loop using the keyword for(). The for() loop structure combines the initialization step and the incrementation step into the for() loop construction:

function setup() {
  createCanvas(300, 300);

  // initialization, condition, and incrementation all in one line
  for (let foo = 50; foo < width; foo = foo + 50)  {
    ellipse(foo, 50, 40, 40);
  }
}

Which should you use? Whichever is easier for you to understand. Remember that most of the time spent programming is fixing problems, and whatever you understand best will probably have fewer problems.

Both for() loops and while() loops can be nested, meaning a loop inside a loop:


function setup() {
  createCanvas(700, 700);
  background(230);
  fill(0);

  let yPos = 0;
  let xPos = 0;

  for (yPos = 30; yPos < height; yPos=yPos + 40) {
    for (xPos = 20; xPos<width; xPos=xPos + 40) {
      circle(xPos,yPos, 5);
    }
  }
}

Functions

Every time you use one of the built-in 'commands', you are really using (or more properly 'calling') a built-in function. Functions are a very important building block of programming, and in addition to using built-in functions, you can also create your own. In fact, you've already been doing that, when you created the setup() and draw() functions. In the case of setup() and draw() you have to use those names, but when you create other functions you can make up your own names. Just like variables names, good function names make your programs easier to understand.

Why create your own functions?

  • Reuse (if it's something you might do again)
  • Clarity (remember your three important audiences: yourself, others learning from you, me when I grade your work)
  • Easier to debug (what is debugging?)
    • One of the most powerful ways to approach a bug is to reproduce it with simplest possible example. This is much easier when the thing that's causing the problem is already a function.
  • Modularity
  • Flexibility (with good choice of parameters)

Let's modify the example from last class to use a function. First let's draw a house instead of a circle to make it a little more interesting:

function setup() {
  createCanvas(300, 300);

  // initialization, condition, and incrementation all in one line
  for (let foo = 50; foo < width; foo = foo + 50)  {
    rect(foo, 50, 40, 40);
    line(foo, 50, foo+20, 30);
    line(foo+20, 30, foo+40, 50);
  }
}

Now let's make a function called drawOneHouse(). If we want to draw a house at different locations, we need a way to tell the function drawOneHouse() where to put the house. Functions accommodate this by allowing us to pass information into the function by putting that information in the parenthesis. In the function, we store this information in temporary variables that we can use in the function:

function setup() {
  createCanvas(300, 300);

  for (let foo = 50; foo < width; foo = foo + 50) {
    drawOneHouseAt(foo);
  }
}

function drawOneHouseAt( x) {
  rect(x, 50, 40, 40);
  line(x, 50, x+20, 30);
  line(x+20, 30, x+40, 50);
}

Notes

  1. I've said this before and I'll keep saying: Choose descriptive names for your variables and functions! foo is a bad name, xPos is a good name, houseXPos is a better name.
  2. The value of foo (50, 100, 150 ...) is the information passed to the function so that the function can do it's work. The proper name for this information is an argument
  3. The variable x is a temporary variable that only exists in the function. This variable is used to store the argument that was passed into the function so that the function can do its work. Once the function is finished, this variable is no longer needed and is destroyed. A variable used in this way is called a parameter
  4. Functions may take zero, one, or multiple arguments. When you write a function, you decide how many arguments you need. For example, we might have included the house size or roof height or house y location. (Of course when you use functions that someone else wrote you must use the proper number of parameters.)
  5. Functions can return information as well, for example the random() function. Functions can either return one piece of information, or none. We will see later how to do this.

Variable Scope (again)

https://editor.p5js.org/mangtronix/sketches/DaceAEVzA

let foo;  // this is a global variable, visible in all functions

function setup() {
  foo = 7;
}

function draw() {

  print(foo);

  let bar; // this is a local variable, visible only inside of draw()

  for (let i = 0; i < width/2; i++) {
    // i is a local variable visible only inside this for() loop
    ellipse(i, height/2, 10,15);
  }
}

Readings / Class Discussion

Debugging

Week 2.2 Additional Resources

Back to top

Week 3

Week 3.1 - 9/9

Artwork examples
Functions

Any questions about what we've covered already?

Functions that return a value: See the reference page for return

Notes

  • Functions can take any number of arguments (or none), but can return at most one

In class exercise:

  1. Write a function that will take a single parameter and draw a vertical line from the top of the canvas to the bottom at the X coordinate indicated by the parameter
  2. Write another function that will draw a horizontal line at the indicated Y coordinate
    1. Test as before
  3. Using these two functions, write a program that draws a grid of lines at regular intervals on the canvas

Callback Functions / Event Handlers

mouseClicked() example in the reference section

Notes

  • You never have to call callback functions. The p5.js system calls them for you when that event happens

See Program flow for more examples of callback functions and event handlers.

https://editor.p5js.org/mangtronix/sketches/7zooOaxnq

const redLocationX = 40;
const redLocationY = 40;

const blueLocationX = 80;
const blueLocationY = 40;

const menuSizeX = 120
const menuSizeY = 80;

const circleDiameter = 40;
const backgroundColor = 240;

function setup() {
  createCanvas(400,400);

  //prepare background
  background(backgroundColor);

  // Put a box around the menu. We won't be allowed to draw here
  rect(0,0, menuSizeX, menuSizeY);

  // draw red circle
  fill (255,0,0);
  circle(redLocationX, redLocationY, circleDiameter);

  // now blue
  fill (0, 0, 255);
  circle(blueLocationX, blueLocationY, circleDiameter);

  // initialize fill to green
  fill (0, 255, 0);

  // turn off stroke
  noStroke();

  // faster refresh rate makes line more solid
  frameRate(200);
}

function draw() {

  if (mouseIsPressed &&
      !mouseIsWithinRect(0, 0, menuSizeX, menuSizeY)) {
    circle(mouseX, mouseY, 15);
  }
}

function mouseClicked() {

   // Have we chosen red?
  if (mouseIsWithinCircle(redLocationX, redLocationY, circleDiameter/2)) {
    console.log("you chose red!");
    fill (255,0,0);
  }

  // Have we chosen blue?
  if (mouseIsWithinCircle(blueLocationX, blueLocationY, circleDiameter/2)) {
    console.log("you chose blue!");
    fill (0, 0, 255);
  }

}

function mouseIsWithinCircle( x, y, radius) {
  if (dist(mouseX, mouseY, x, y) < radius) {
    return true;
  }
  return false;
}

function mouseIsWithinRect( x, y, sizeX, sizeY) {
  if (mouseX > x &&
      mouseX < x + sizeX &&
      mouseY > y &&
      mouseY < y + sizeY) {
    return true;
  }
  return false;
}

Notes

  • Operator precedence is very complicated. It is best to put parenthesis to force the order you want.

Week 3.2 - 9/11

Topics today

  • Work example
    • Bloom by Brian Eno and Peter Chilvers
    • App which allows user to create relaxing music / visuals within a generative system
      • User taps to create a looping note that fades away over time
      • Notes are constrained to a pleasing musical scale initially chosen by the artist
  • Arrays
  • Object Oriented Programming
  • Transformations

Arrays

Very simply, arrays let you store multiple things under one variable name, and let you identify which thing you want by using an index

function setup() {
  const numberOfValues = 10;

  let values = []

  let n = 0;
  while (n < numberOfValues ) {
    values.push( n * n );
    n = n + 1;
  }

  for (let i = 0; i < values.length; i++) {
    print(values[i]);
  }
}

Things to notice

  • Similar to the way functions are signified by (), arrays are signified by []

  • Arrays can be of any data type, but can't be mixed types

  • New keyword: const

  • Why not just use ten "normal" variables?

  • Arrays and loops (either for() or while()) almost always show up together. If you have an array, you almost always want a loop.

  • Note that the while() loop used to put the numbers into the array is exactly the same as the for() loop used to print the array. I could have used either in both places. I did this to show you that they are interchangeable.

  • Some ways to iterate over an array

  • See Week 3.2 - Arrays (p5editor) for examples on how to insert and remove items

Object Oriented Programming (OOP)

Walk through these examples:

Transformations

Walk through this tutorial. You might also find this useful for a slightly different perspective.

Back to top

Week 4

Week 4.1 - 9/16

  • Announcements
    • Do you want to host an IM workshop? Contact Instructor Stefania IM Workshop
Tool Training
  • You must complete the tool training with the Lab Instructors to have access to the lab tools
  • If you do not successfully complete the tool training during class time you must make arrangements to complete it with the Lab Instructors

Week 4.2 - 9/18

Plan for today

Additional p5js resources:

Working with text

Text on the canvas
The most basic usage

Week 4 - Basic Text

function setup() {
  createCanvas(400, 400);

  text("My Important Message", width / 2, height / 2);
}
Different Fonts and Position

Week 4 - Basic Text

function setup() {
  createCanvas(400, 400);
	textFont("Courier New", 25);

	text("My Important Message", width / 2, height / 2);
}

Fonts that seem to be available are 'Courier New' (monospace), and 'Helvetica' (non-monospace)

You can also load your own fonts but that requires uploading them to the p5.js server

Help->Reference->LoadFont Typography (p5 reference)

Important: Note that p5.js is asynchronous, meaning that setup() will continue even if the loadFont() hasn't finished. There are two ways to force your program to wait for the font to load:

  1. Use preLoad()
  2. Specify an optional callback function in loadFont()
Selecting one of many fonts

Note that loading a font takes time, so if you expect to use multiple fonts it's best to preload all of them, and then switch between them using textFont()

Other things to do with text

There are of course many other things you can do with text. You can look at Help->Reference->Typography and File->Examples->Typography for ideas and examples.

Data Visualization

What is data visualization? Here are some examples:

Finding data

Note: your data source must be available via an https (SSL-encrypted) URL in order for it to be loaded dynamically from a sketch hosted on an https server (like https://p5editor.p5js.org). Sites starting with http:// will not work. For static data you can download the .csv file to your computer and then add it to your sketch files.

Week 4 JSON http vs https (p5editor)

Sources

Format

  • The most common format is CSV. You can create your own CSV file from a spreadsheet because most programs (Excel, OpenOffice Calc, Google Sheets) can export any table in CSV format
  • Other formats are JSON and XML. We won't spend any time on them, but there are p5.js libraries for these.
Simple CSV example
Worked example: Getting and working with a CSV file
  • A database of energy generated by wind turbines
  • Click "Get Data"
  • Scroll down a bit to "Tabular Data: CSV format" and click on "CSV format".
    • This will download a .zip file.
  • Unzip the file.
    • This will create uswtdb_v4_1_20210721.csv
  • This is a plain text file; you can view it with a text editor
    • You will see that the first line is the heading of each column
    • Some of the fields are numerical (e.g. case_id)
    • Some of the fields are text (e.g. t_state, t_county)
    • Some of the fields are missing (e.g. faa_ors, faa_asn)
  • Now you can load this file into an array of Strings and then process each line one at a time, pulling out individual fields:

Week 4 - Datavis with csv

/*
 * example to process a CSV file containing data
 * about wind turbines in the USA
 * Source: https://eerscmap.usgs.gov/uswtdb/
 */

// An array of strings to hold the entire file
let strings = [];

// For scaling, we want to know the minimum and maximum latitude and longitude
let minLat;
let maxLat;
let minLong;
let maxLong;

function preload() {
  // The text from the file is loaded into an array.
  strings = loadStrings("uswtdb_v4_3_20220114.csv");
}

function setup() {
  createCanvas(500, 400);
  background(235);

  // Did we succeed to load anything?
  if (strings == null) {
    print("failed to load the file, stopping here");

    // this is an endless loop; it's a common way
    // to prevent a program from continuing when
    // something is so wrong that there is no sense
    // in continuing
    while (true) {}
  }

  print(
    "strings loaded from file successfully, read " + strings.length + " lines"
  );

  // Find the minimum and maximum latitude
  // and longitude
  findMinMaxLatLong();
}

function findMinMaxLatLong() {
  let singleRow = [];

  // loop over each row in the file
  for (let csvRowNumber = 1; csvRowNumber < strings.length; csvRowNumber++) {
    // get a single row and split that row
    // into individual words
    singleRow = split(strings[csvRowNumber], ",");

    // We know that the last two fields are the
    // latitude and longitude and so they are
    // numerical:
    let longitude = float(singleRow[25]);
    let latitude = float(singleRow[26]);

    // The file may be missing a field, in which case
    // the converstion to a float might have failed
    if (isNaN(longitude) || isNaN(latitude)) {
      print("conversion to float failed; skipping row " + csvRowNumber);
    } else {
      if (csvRowNumber == 1) {
        minLat = latitude - 10;
        maxLat = latitude + 10;
        minLong = longitude - 10;
        maxLong = longitude + 10;
      }

      if (latitude < minLat) minLat = latitude;
      if (latitude > maxLat) maxLat = latitude;
      if (longitude < minLong) minLong = longitude;
      if (longitude > maxLong) maxLong = longitude;
    }
  } // end of for() loop

  print("Latitude (min, max) = (" + minLat + "," + maxLat + ") ");
  print("Longitude (min, max) = (" + minLong + "," + maxLong + ")");
} // end of findMinMaxLatLong

let csvRowNumber = 1;
// Skip the first line, since we know it's a header

function draw() {
  let singleRow = [];

  // get a single row and split that row into
  // individual words
  singleRow = split(strings[csvRowNumber], ",");

  // This really slows things
  // down so use only when debugging
  //println("Row " +
  // csvRowNumber +
  //   " contains " +
  //   singleRow.length +
  //   " fields" );

  // We know that the last two fields are the
  // latitude and longitude and so they are
  // numerical:
  let longitude = float(singleRow[25]);
  let latitude = float(singleRow[26]);

  // use only when debugging
  // println("Latitude " +
  // latitude +
  //   " longitude " +
  //   longitude );

  // Check for non-numerical strings.
  if (isNaN(longitude) || isNaN(latitude)) {
    print("conversion to float failed; skipping row " + csvRowNumber);
  } else {
    // scale that to fit on our canvas
    //println(csvRowNumber);
    let ypos = map(latitude, minLat, maxLat, 0, height);
    let xpos = map(longitude, minLong, maxLong, 0, width);

    // Put a mark there
    point(xpos, ypos);
  } // end of valid data

  csvRowNumber++;
  if (csvRowNumber >= strings.length) {
    println("finished");
    noLoop();
  }
}

Things to notice:

  1. The split() function does half the magic
  2. The int() or float() function does much of the rest
  3. data files might have errors in them and you need to defend your program against them
  4. loop() and noLoop() can be used anytime you want to start or stop the draw() function from repeating
JSON and XML: Other file formats

JSON and XML are other format for organizing data in a file. They are more complex than CSV, and again p5.js provides functions.

Generative Text

Pull words from a CSV file and by using random() in a clever way, write poems or slogans or whatever.

Week 4 - Fill in the blank Here is a terribly lame example:

/*
Generate poetry from a file of words
 the file has words in this format:

 roses,red,violets,blue,dream,disneyland

 we will refer to them as:

 item1,color1,item2,color2,verb,location

 and construct a poem:

 item1 are color1, item2 are color2
 when I verb I verb to location
 */

// Let's put the index of the word into numbers:
let ITEM1 = 0;
let COLOR1 = 1;
let ITEM2 = 2;
let COLOR2 = 3;
let VERB = 4;
let LOCATION = 5;
// final means that I will not change these variables
// It is conventional to use all caps for variable names that will not change


let strings = [];

function setup() {

  // The text from the file is loaded into an array.
  strings = loadStrings("words.csv");

  // How many lines did we get?
 // println("strings array contains this many lines: " + strings.length);
}

let csvRowNumber = 0;

function draw() {
  let singleRow = [];

  // First line: "item1 are color1, item2 are color2"

  // Pick a random number, round that number DOWN to a whole number,
  // and split that row into individual words
  singleRow = split(strings[int (random(strings.length))], ',');
  // get item1
  let item1 = singleRow[ITEM1];

  // Now keep doing this for each word
  singleRow = split(strings[int (random(strings.length))], ',');
  // get color1
  let color1 = singleRow[COLOR1];

  // Now the second half of the first line: "violets are blue"
  singleRow = split(strings[int (random(strings.length))], ',');
  let item2 = singleRow[ITEM2];
  singleRow = split(strings[int (random(strings.length))], ',');
  // get color2
  let color2 =  singleRow[COLOR2];

  // that's the end of the first line of the poem
  print(item1 + " are " + color1 + ", " + item2 + " are " + color2);

  // Now the second line: when I verb I verb of location
  message = "When I " ;
  singleRow = split(strings[int (random(strings.length))], ',');
  message += singleRow[VERB];

  message += ", I ";
  singleRow = split(strings[int (random(strings.length))], ',');
  message += singleRow[VERB];

  message += " to the ";
  singleRow = split(strings[int (random(strings.length))], ',');
  message += singleRow[LOCATION];
  print(message);

  // that's the end of the second line of the poem so start a new line
  // and also put an extra blank line
  print('\n');
  print('\n');

  noLoop(); // Wait for a mouse click then do it again
}

// If you click the mouse, allow the draw() function to resume
function mouseClicked() {
  loop();
}

and this is an example of the words you can feed it. put these contents into a file called words.csv:

roses,red,violets,blue,dream,disneyland
robots,silver,pencils,grey,run,supermarket
goldfish,orange,motors,white,turn,workbench
books,multicolored,lamposts,azure,swim,island
computers,black,mice,pink,squeak,home

Back to top

Week 5

Week 5.1 - 9/23

Plan for today

Homework feedback to all:

  • Better comments. I should be able to read your code and comments and completely understand your program.
    • Your code should explain what is really happening. things = 2; // increase the number of things is wrong. It is setting the number of things to 2, not increasing the number of things.
  • Better formatting:
    • Remove unnecessary spaces
    • Break long lines (both code and comments) into short lines. A line should fit in the p5.js editor window.
  • Remove unnecessary functions, or explain why they are there
  • Remove unnecessary variables, or explain why they are there
  • Instead of naming functions thing1, thing2, thing3, give them meaningful names like happyFace, sadFace, and surprisedFace
  • Any time you have more than 2 or 3 objects they should probably be in an array. If there is a reason not to have them in an array you need to explain why in the comments.
  • Read the assignment carefully and make sure you provide everything that is requested
  • If draw() is empty explain why
  • Don't include your entire program in the README.md. You may include short pieces to augment your description.
  • Explain the arguments to functions, or better yet, use names that are so clear that no comments are needed. constructor(wid,hgt,rnd,clr) I could guess that wid is width and hgt is height, but why not use the full word? You are all fast typists. Better yet, if you are drawing e.g. a car, name the variables carWidth and carHeight. clr and rnd I could not figure out except by seeing how they were used, but I shouldn't have to do that.
  • A function that only calls another function e.g. is almost certainly pointless. if there is a reason, it should be explained.
foo() {
	this.bar()
}
  • If code is commented out, explain why
  • If the video clip is in your GitHub repo, embed it in the README.md
    • If the video clip is on Vimeo or YouTube, put a link in your README.md
  • Tidy your code before putting it on GitHub
  • Use the correct suffix for your variables, classes, and functions. If a class defines a single car, don't call it cars. If individual cars are then gathered in an array of multiple cars, don't call it arrayCar.
  • Try to avoid hardcoded or magic numbers. Use built-in variables (width/2 instead of const CENTER = 200) whenever possible. If you must use numbers explain why.
  • Start your homework early so that there is time to meet with me if you need help. I'm willing to meet on the weekend but not late Monday night.

Working with images!

The p5.Image class

  • Just another class, i.e. it has
    • Data (the pixels, width, height, etc.)
    • Functionality (image(), get(), etc.)
let catImg;
function preload() {
  photo = loadImage("https://upload.wikimedia.org/wikipedia/commons/thumb/b/bc/Juvenile_Ragdoll.jpg/440px-Juvenile_Ragdoll.jpg");
}
function setup() {
  createCanvas(400, 400);
  background(255);
  image(photo, 0, 0); // this actually displays the image
}
  • image(photo, positionX, positionY, width, height) - display this image at this location and scale to this size
  • photo.resize(w,h) - scale to this size. If one of the arguments is zero, then scale to the remaining argument and retain the original aspect ratio.
  • photo.get(x,y,w,h) - Returns a new p5.Image containing a portion of the image
  • photo.get(x,y) - Returns the color of the pixel at this location
let catImg;
function preload() {
  catImg = loadImage("https://upload.wikimedia.org/wikipedia/commons/thumb/b/bc/Juvenile_Ragdoll.jpg/440px-Juvenile_Ragdoll.jpg");
}
function setup() {
  createCanvas(400, 400);
  background(255);
  image(catImg, 0, 0);

  let newImg = catImg.get( 50,60, 100,50);
  image (newImg, 250, 200);
}

For more information and ideas

  • Reference page for p5.Image for other methods
  • Examples -> image

Week 5.2 - 9/25

Plan for this week:

  • Pixels array
  • Sprite sheets
  • Sound
  • Introduce midterm project
    • Each student makes their own project
  • Additional tutorials

The pixels array: Treating the canvas as an image

You can access individual pixels from the canvas (and whatever is on the canvas) using the special built-in array called pixels. Before using this array you must load everything from the canvas into the pixels array using the loadPixels() function, and after making any changes you must call updatePixels() to write from the pixels array back to the canvas if you want to make the changes visible

Week 5 - updatePixels

function setup() {
  let pink = color(255, 102, 204);
  loadPixels();
  let d = pixelDensity();
  let halfImage = 4 * (width * d) * ((height / 2) * d);
  for (let i = 0; i < halfImage; i += 4) {
    pixels[i] = red(pink);
    pixels[i + 1] = green(pink);
    pixels[i + 2] = blue(pink);
    pixels[i + 3] = alpha(pink);
  }
  updatePixels();
}
  • The pixels array is one-dimensional, meaning if you want to go to a different row on the canvas you need to offset by that many widths
  • Each pixel occupies 4 positions in the array
  • Thus the equation for accessing a given pixel is (x + y * width) * 4
  • Remember to set pixelDensity(1); in case you have a high resolution display
function setup() {
  pixelDensity(1);

	// blue background
	// makes it easier to see the pink
  background(0, 102, 204);

  loadPixels();

	// Here is the equation
	// for the start (red value)
	// of a pixel
	// at a particular coordinate (x,y)
  // (x + y*width) * 4

  // Change most of the fiftieth row to pink
  // instead of the whole line,
	// only do from x = 10 to x = 90
  for (let i = (10 + 50 * width) * 4;
       i < (90 + 50 * width) * 4;
       i += 4) {

		// pink
    pixels[i + 0] = 255;
    pixels[i + 1] = 102;
    pixels[i + 2] = 204;
    pixels[i + 3] = 100;
  }

	// this puts the array back on the screen
  updatePixels();
}

It's important to remember that a pixel is just four numbers so you can manipulate pixels mathematically e.g. make it fade:

function setup() {
  pixelDensity(1);
  background(0, 102, 204);
}

let redValue = 0;

function draw() {

  loadPixels();

  for (let i = 0; i < width * height * 4 ; i+=4) {
    pixels[i] = redValue;
  }
  updatePixels();

  redValue = (redValue + 1 ) %255
  print(redValue);

  updatePixels();

}

Just for fun, here is the last example from the video where Dan created a random (only in the green channel) background:

function setup() {
  createCanvas(256,256);
  pixelDensity(1);
}

function draw() {
  loadPixels();
  for (var y = 0; y < height; y++) {
    for (var x = 0; x < width; x++) {
      var index = (x + y * width) * 4;

      pixels[index + 0] = x;
      // red value changes horizontally

      pixels[index + 1] = random(255);
      // green value random

      pixels[index + 2] = y;
      // blue value changes vertically

      pixels[index + 3] = 255;
      // no transparency
    }
  }
  updatePixels();
}

Look at the reference page for the pixels array

A fun examples from Professor Sherwood:

let tiles = [];
let tileSize = 100;

function preload() {
  img = loadImage("aiweiwei.jpeg");
}

function setup() {
  createCanvas(400, 400);
  let numTiles = img.height / tileSize;
  while (numTiles > 0) {
    tiles.push(
      img.get(
        int(random(img.width - tileSize)),
        int(random(img.height - tileSize)),
        tileSize,
        tileSize
      )
    );
    numTiles--;
  }
  imageMode(CENTER);
}

function draw() {
  push();
  translate(width / 2, height / 2);

  let numSegments = 10;
  let eachAngle = TWO_PI / numSegments;
  let whichImage = int(random(tiles.length));

  for (let i = 0; i < numSegments; i++) {
    let x = cos(eachAngle * i) * tileSize + 1;
    let y = sin(eachAngle * i) * tileSize + 1;
    push();
    translate(x, y);
    rotate(eachAngle * i);
    image(tiles[whichImage], 0, 0);
    pop();
  }

  pop();
  noLoop();
}

function keyPressed() {
  loop();
}

Can we use a sequence of images for animation?

Download this to your laptop: https://github.com/michaelshiloh/IntroductionToInteractiveMedia/blob/master/media/walking.png

How would we use them?

Week 5 - Walk animation

let spritesheet;
let sprites = [];
let direction = 1; // 0 up
let step = 0;
let x;
let y;
let speed = 3;

function preload() {
  spritesheet = loadImage("walking.png");
}

function setup() {
  // fullscreen(true);
  createCanvas(500, 450);

  // 12 images across, 4 down, in the spritesheet

  let w = int(spritesheet.width / 12);
  let h = int(spritesheet.height / 4);

  for (let y = 0; y < 4; y++) {
    sprites[y] = [];
    for (let x = 0; x < 12; x++) {
      sprites[y][x] =
        spritesheet.get(x * w, y * h, w, h);
    } // iterate over rows
  } // iterate over columns

  x = width / 2;
  y = height / 2;

  imageMode(CENTER);

	// Display first sprite
  image(sprites[direction][step], x, y);
}

// nothing to do here because all the action
// happens in the keyPressed() callback
function draw() {}

function keyPressed() {
  // look at sprite sheet to determine
  // which direction is which row

  if (keyCode === DOWN_ARROW) {
    direction = 0;
    y += speed;
  }

  if (keyCode === LEFT_ARROW) {
    direction = 1;
    x -= speed;
  }

  if (keyCode === RIGHT_ARROW) {
    direction = 2;
    x += speed;
  }

  if (keyCode === UP_ARROW) {
    direction = 3;
    y -= speed;
  }

	// Every so often
	// advance to the next sprite
  if (frameCount % speed == 0) {
    step = (step + 1) % 12;
  }

	// Finally draw paint the sprite
  background(255);
  image(sprites[direction][step], x, y);
}

You can probably find many sprite sheets by googling "sprite sheet" + whatever you want.

Sound!

Upload this to your p5 editor: https://github.com/mangtronix/IntroductionToInteractiveMedia/blob/master/media/doorbell.mp3

Very basic example:

Week 5 - Sound

/*
Must upload doorbell.mp3
Must include sound library in index.html
*/

function preload() {
  song = loadSound('doorbell.mp3');
}

function setup() {
  background(234);
  song.play();
}

function draw() {
  if (song.isPlaying()) {
    print("song is playing")
  } else {
    print("song is not playing")
    noLoop
  }
}

function mouseClicked() {
  if (song.isPlaying()) {
    song.stop();
  } else {
    song.play();
  }
}

As always, it's useful to explore the examples and the reference page

Remember Sound requires a separate library which must be included and to record sound it has to be enabled in the security preferences.

Sound Synthesis

The other way to make sounds is to create them mathematically

Working in groups (time permitting):

If we had multiple sound files, how would we play the next one when we click the mouse? What graphical effects can you synchronize to the sound?

Back to top

Week 6

Week 6.1 - 6/30

Plan for today:

Homework feedback

Working with a camera: Computer Vision!

Basic sketch showing how to get input from camera:

Week 6 - Capture

let capture;

function setup() {
  createCanvas(200, 200);
  capture = createCapture(VIDEO);
  capture.hide();
}

function draw() {
  image(capture, // what image to display
        0, 0,    // where to place the image on the canvas
        width,   // width to display

        // the height is more complicated:
        // we want the capture height to be
        // the width multiplied by the aspect ratio
        width * capture.height / capture.width);
}

Reference page for createCapture

Some video examples:

  • Simple frame differencing, similar to the method in Golan Levin's article
  • A more complex example by Prof. Aaron that uses frame differencing to detect which vertical slice of the camera image has the most motion, and trigger a corresponding sound clip

Posenet

Week 6.2 - 10/2

Plan for today:

Review frame differencing

  • If you wanted to display white (instead of the color of the difference) wherever motion above a certain threshold is detected, how would you do this?
  • Video Mirror (flipping the x)
  • In class exercise: Can you trigger sounds according to where there is motion? You might want to borrow ideas from here

Random items

Grids
  • An example by Prof. Mathura showing how to create and move in a grid
Perlin Noise

Week 6 - Random line

function draw() {
  background(204);
  let n = random(0, width);
  line(n, 0, n, height);
}

What if we wanted the line to move in a more organic, lifelike fashion? Organic things (e.g. butterflies, leaves blowing in the wind, clouds) don't jump instantly from one place to another, they tend to move close to where they were last time

Week 6 - Perlin noise line

let offset = 0.0;

function draw() {
  background(204);
  offset = offset + .01;
  let n = noise(offset) * width;
  line(n, 0, n, height);
}

Things to notice:

  • Why is the variable offset global? (Remember our discussion of variable scope)
Other things you can do with arrays

Look at other array methods in the reference page:

Blocking vs. non-blocking functions
  • What are blocking and non-blocking functions?
  • How do you know when a non-blocking function is done?
  • Soundfile reference page
Game techniques
Other resources

Creative Coding lecture notes

Coding Train tutorials (by Dan Shiffman)

A nice set of p5.js tutorials by Happy Coding

Back to top

Week 7

Week 7.1 - 10/7

  • GitHub tutorial
  • Project status, debugging
GitHub
  • What is GitHub?
  • Difference between an account and a repository
  • Follow along with me and create an account
  • Instructions for this are here.

Please use your name for your account name so that I can more easily recognize it. If you don't want to use your name for privacy reasons, please choose an alias that I can recognize as you.

Name your repository "introduction to interactive Media".

Week 7.2 - 10/9

Plan for today:

  • Midterm project presentations

  • Homework:

    • Check main page
    • Bring any adapter you need from USB-A to your computer for the first class after the break

FALL BREAK / FALL BREAK / FALL BREAK

Week 8-14 lecture notes
