ELEC

ELEC is a lightweight local GUI for Let's Encrypt certificate issuance. It can run as a Windows desktop app from source or .exe, or as a self-hosted Docker service with the same web UI.

What It Solves

• Save a domain profile once with its DNS provider and credentials.
• Reuse that profile to issue fresh certificates for subdomains, SAN sets, or *.example.com wildcard names.
• Export PEM bundles and optional PFX bundles.
• Preview a hosts-file mapping such as 192.168.1.1 gateway.example.com for local appliances like a Ubiquiti Cloud Gateway.
• Backup and restore the full ELEC data set when moving to another machine.
• Build a Windows .exe package from the project.
• Host the UI in Docker for always-on certificate operations.

Star History

Requirements

• Node.js 22+ for source/development mode.
• Control over the public DNS zone for the domain you want to validate.
• DNS provider API credentials supported by lego.

Development

• Install dependencies: npm install --cache .npm-cache
• Run in dev mode: npm run dev
• Run normally: npm start
• Smoke test: npm run smoke
• Validation tests: npm test

Then open http://127.0.0.1:3210 if the browser does not launch automatically.

Windows EXE Build

• Build the packaged app: npm run build
• Output file: build/ELEC.exe

The current packaging path uses pkg with a generated CommonJS packaging target so the standalone executable starts cleanly.

Docker

Docker Compose

• Start the service: docker compose up --build -d
• Open the UI: http://127.0.0.1:3210
• Stop it: docker compose down

The default compose file stores ELEC state in the named volume elec-data.

Docker Build / Run

• Build the image: docker build -t elec .
• Run it: docker run -d --name elec -p 3210:3210 -v elec-data:/app/.elec-data elec

Docker Notes

• The image pins lego to v4.31.0 by default and installs the Linux binary into /usr/local/bin/lego.
• ELEC_HOST=0.0.0.0, ELEC_AUTO_OPEN=false, and ELEC_LEGO_BINARY_PATH=/usr/local/bin/lego are set in the container so the service is reachable and does not try to launch a local browser.
• The Windows-only shell actions such as Browse for folders and Open Export Folder are not available in Docker or non-Windows environments.
• For persistence, keep /app/.elec-data on a volume or bind mount.

Nginx SSL Template

A ready-to-edit SSL reverse-proxy template is included at deploy/nginx/elec-ssl.conf.template.

Typical use:

• replace example.com with your hostname
• replace the certificate and key paths with your real TLS files
• keep 127.0.0.1:3210 if Nginx runs on the same host, or change it to your Docker service name such as elec:3210
• test with nginx -t
• reload with systemctl reload nginx

The template disables proxy buffering so ELEC's live certificate task logs continue streaming correctly through Nginx.

Quick Start

1. Run start-elec.bat, npm start, or docker compose up --build -d.
2. Save your ACME email and output settings.
3. Create a domain profile with the root domain, DNS provider, and provider credential JSON.
4. Issue a certificate for names such as gateway.example.com or *.example.com, example.com.
5. Use the generated hosts preview to point the public certificate name at your LAN IP if needed.

Notes

• Let's Encrypt does not permanently trust a domain after one issuance. Each new certificate is validated again, but ELEC makes that fast by reusing your stored DNS automation profile.
• For wildcard issuance, use DNS-01 and include both *.example.com and example.com if you want the apex covered too.
• On Windows desktop, the app can auto-download lego.exe unless you provide a custom path in Settings.
• In Docker, the Linux lego binary is preinstalled and exposed through ELEC_LEGO_BINARY_PATH.
• Secrets are encrypted locally using a generated AES key stored in .elec-data/local/secretbox.key.
• The backup ZIP includes config, encrypted secrets, exports, logs, lego data, and the local key material required to decrypt saved credentials on the restored instance.

Storage

ELEC stores its working data inside the project or container working directory by default:

• .elec-data
• .elec-data/local

That includes config, encrypted secret blobs, logs, lego state, and exported certificate artifacts. You can override the locations with ELEC_STORAGE_ROOT and ELEC_LOCAL_STORAGE_ROOT if you want them elsewhere.
